Advanced TIR optics provide high efficiency and focus. High-intensity automotive-type LEDs. Pin-fin heatsink design. Integrated Deutsch-style connector. Durable powdercoated aluminum construction. Engineered and Manufactured in USA.
Specifications:
Description_ASC |
Included in the box: Five (5) Stage Series 5in LED Pods. Four (4) CrossLinks with hardware. One (1) CrossLink support with hardware. One (1) CrossLink endmount kit. One (1) Ultra Heavy-Duty Terminating splitter. Three (3) Ultra Heavy-Duty CrossLink splitters. One (1) Deutsch-style wire pigtail. |
Description_DEF |
Light Bar Mounting Kit |
Description_DES |
Pod light featuring advanced TIR optics for high efficiency and focus. |
Description_EXT |
Advanced TIR optics provide high efficiency and focus. High-intensity automotive-type LEDs. Pin-fin heatsink design. Integrated Deutsch-style connector. Durable powdercoated aluminum construction. Engineered and Manufactured in USA. |
Description_INV |
Diode Dynamics Offroad |
Description_MKT |
Advanced TIR optics provide high efficiency and focus. High-intensity automotive-type LEDs. Pin-fin heatsink design. Integrated Deutsch-style connector. Durable powdercoated aluminum construction. Engineered and Manufactured in USA. |
Description_SHO |
Offroad |
Add-On |
N |
Color Temp |
6000K |
Compliance Rating |
SAE J581 Driving/Auxiliary High Beam Pattern |
Input Power (watts) |
90 |
Measured Output (lumens) |
9,700 lm |
Operating Temperature |
-40C to 85C (-40F to 185F) |
Operating Voltage |
9-16V |
Prop 65 Yes/No |
N |
Title |
Diode Dynamics - SS5 Pro Universal CrossLink 5-Pod Lightbar White Driving |
Length |
12.0000 |
Width |
15.0000 |
Height |
18.0000 |
Weight |
18.0000 |
