| Description_ASM |
Fits Chrysler 273, 318, 340 and 360 LA |
| Description_DEF |
Engine Camshaft |
| Description_DES |
Xtreme Energy 212/218 Hydraulic Flat Cam for Chrysler 273-360 |
| Description_KEY |
273, 360, 318, AMC, Dodge, Mopar, Plymouth, Dart, Road Runner, Charger, Challenger, 383, 400, 440, 426, HEMI, 426 Wedge, 426 HEMI, RB, B, HEMI, 392, Chrysler, LA |
| Description_INV |
XE 212/218 Hyd Flat Cam Chrysler 273-360 |
| Description_EXT |
Strong torque through low end and mid-range, good idle. |
| Description_SHP |
None |
| Description_SHO |
XE 212/218 HFTChryLA |
| Description_MKT |
Featuring a quicker valve opening, the Xtreme Energy camshaft profile provides increased responsiveness and more area under the lift curve than older, slower grinds. Designed to increase performance without sacrificing driveability and creature comforts, the Xtreme Energy grind family offers gains in torque and horsepower while still delivering adequate vacuum for power brakes and other vacuum dependent accessories. Xtreme Energy camshafts work great in carbureted applications, but offer the best performance with aftermarket intake manifolds, lower gear ratios, headers and free flowing exhaust. |
| Cam Type |
Hydraulic Flat Tappet |
| Amazon ASIN |
B000N5OLH0 |
| Grind Number |
XE256H |
| K-Kit Upgrade |
K20-221-3 |
| C.A.R.B. Exempt for On-Road Vehicles? |
No |
| Intake Duration at .050 Inch Lift |
212 |
| Advertised Exhaust Duration |
268 |
| Exhaust Duration at .050 inch Lift |
218 |
| C.A.R.B. Exemption Reason |
N/A |
| Camshaft Gear Attachment |
1-Bolt |
| Cam and Lifter Kit Upgrade |
CL20-221-3 |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles? |
Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967? |
Yes, but must meet tailpipe emission standards for year of vehicle. |
| Basic Operating RPM Range |
1,000-5,200 |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967? |
Yes, but must meet tailpipe emission standards for year of vehicle. |
| Intake Valve Lift |
0.447 |
| Valve Springs Required |
Yes |
| Advertised Intake Duration |
256 |
| Exhaust Valve Lift |
0.455 |
| Lifter Type |
Hydraulic Flat Tappet |
| Usage |
Street/Performance |
| Camshaft Material |
Cast Iron |
| SK-Kit Upgrade |
SK20-221-3 |
| Lobe Separation |
110 |
| Camshaft Series |
Xtreme Energy |
| C.A.R.B. E.O. Number |
N/A |
| Assembly Lubricant Included |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Engine Family |
Chrysler 273-360 c.i. 8 Cylinder (1964-2002) |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965? |
Yes, but must meet tailpipe emission standards for year of vehicle. |
| Title |
Xtreme Energy 212/218 Hydraulic Flat Cam for Chrysler 273-360 |
| Lifters Included |
No |
| Length |
3.0000 |
| Width |
3.0000 |
| Height |
24.0000 |
| Weight |
10.0000 |
