The Centerforce(R) II Clutch Series utilizes a full facing disc with premium friction material and a pressure plate with centrifugal weights (where applicable). Furthermore, static clamp load is increased via our patented machining processes; this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Specifications:
| Description_ABR |
CFT |
| Description_ASM |
1978 thru 1993 Dodge Cars and Trucks 4 Cylinders |
| Description_DES |
Centerforce(R) II, Clutch Pressure Plate and Disc Set |
| Description_DEF |
Clutch Pressure Plate and Disc Set |
| Description_LAB |
P.Plate, Disc, A.Tool |
| Description_INV |
Centerforce, Clutch Cover/Disc |
| Description_EXT |
Centerforce(R) II Clutch Series utilizes our centrifugal weights and patented machining processes for superb holding power and maximum clutch life. |
| Description_FAB |
8-7/8" Diameter; |
| Description_SHO |
Clutch Cover/Disc |
| Description_SLA |
Clutch Pressure Plate and Disc Set, Centerforce II, 8-7/8-IN/225-MM, 1-IN - 23M Spl., Sprung Full face Organic Disc |
| Description_MKT |
The Centerforce(R) II Clutch Series utilizes a full facing disc with premium friction material and a pressure plate with centrifugal weights (where applicable). Furthermore, static clamp load is increased via our patented machining processes; this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc. |
| Clutch Disc Diameter |
8-7/8 |
| Clutch Disc Diameter |
225 |
| Disc Material |
Organic |
| California Proposition 65 |
WARNING - Includes Nickel - cancer. www.P65Warnings.ca.gov. |
| Counterweight Assist |
No |
| Disc Type |
Full face |
| Disc Type Sprung Solid |
Sprung |
| Input Shaft Diameter |
1 |
| Input Spline Quantity |
23M |
| Material |
Cast Iron Pressure Plate / Organic Friction |
| Title |
PN: CFT581780 - Centerforce II, Clutch Pressure Plate and Disc Set |
| Torque Capacity |
330 |
| Length |
4.0000 |
| Width |
14.0000 |
| Height |
14.0000 |
| Weight |
16.0000 |
