IMPORTANT NOTE! This DYAD DS Assembly is a Low Profile Assembly for use with a Gen III Hemi engines using an aftermarket Bellhousing/transission with a Left Drivers Side Aftermarket Starter. The Centerforce(R) DYAD DS 10.4" twin disc clutch has been developed for vehicles requiring a holding capacity of 500 to 1300 ft/lbs of torque at the crank. The pressure plate features our patented centrifugal weight system for superior clamp load over stock and our patented ball bearing actuated pressure plate providing light pedal effort. The discs are equipped with organic segmented facings providing increased holding capacity and the sprung/dampened drive disc provides smooth drivability. DYAD DS clutches are equipped with a lightened billet steel flywheel providing low inertia resulting in quicker RPM's. Components are designed, machined and assembled in the USA. DYAD DS clutches are match balanced and ready for installation using the included ARP fasteners.
Specifications:
| Description_APS |
Dodge s Crate Engines & Swaps Gen III HEMI 8 Cylinders |
| Description_ABR |
MDA |
| Description_ASM |
Dodge s Crate Engines & Swaps Gen III HEMI 8 Cylinders |
| Description_DEF |
Transmission Clutch and Flywheel Kit |
| Description_DES |
DYAD(R) DS 10.4, Clutch and Flywheel Kit |
| Description_FAB |
Drivers Side Aftermarket Starter; |
| Description_LAB |
Cover, Discs, Floater, Flywheel, Bolts, Align Tool |
| Description_INV |
Centerforce, Full Kits W/Flywheel |
| Description_EXT |
The Centerforce(R) DYAD(R) DS (Drive System) 10.4 Inch patented multi-disc clutch offers smooth engagement, light pedal, and high-end holding capacity for engine torque levels from 500 to 1300 ft /lbs. |
| Description_MKT |
IMPORTANT NOTE! This DYAD DS Assembly is a Low Profile Assembly for use with a Gen III Hemi engines using an aftermarket Bellhousing/transission with a Left Drivers Side Aftermarket Starter. The Centerforce(R) DYAD DS 10.4" twin disc clutch has been developed for vehicles requiring a holding capacity of 500 to 1300 ft/lbs of torque at the crank. The pressure plate features our patented centrifugal weight system for superior clamp load over stock and our patented ball bearing actuated pressure plate providing light pedal effort. The discs are equipped with organic segmented facings providing increased holding capacity and the sprung/dampened drive disc provides smooth drivability. DYAD DS clutches are equipped with a lightened billet steel flywheel providing low inertia resulting in quicker RPM's. Components are designed, machined and assembled in the USA. DYAD DS clutches are match balanced and ready for installation using the included ARP fasteners. |
| Description_SHO |
Full Kits W/Flywheel |
| Description_SLD |
DYAD DS, 10.4-IN, 1.125-IN - 26 Spl., Twin Disc |
| Description_SLA |
Clutch and Flywheel Kit, DYAD DS, 10.4-IN/264.2-MM, 1.125-IN - 26 Spl., Sprung; Mixed Organic Twin Disc |
| Alignment Tool Included |
Yes |
| Disc Type |
Mixed |
| Disc Type Sprung Solid |
Sprung |
| California Proposition 65 |
WARNING - Includes Nickel - cancer. www.P65Warnings.ca.gov. |
| Mounting Hardware Included |
Yes |
| Input Shaft Diameter |
1.125 |
| Input Spline Quantity |
26 |
| Counterweight Assist |
YES |
| Flywheel Crank Bolt Size |
M10 x 1.00 x 25 |
| Ring Gear O.D. |
13.205 |
| Made In The USA |
Assembled |
| Clutch Disc Diameter |
10.4 |
| Clutch Disc Diameter |
264.2 |
| Crankshaft Bolt Hole Quantity |
8 |
| Disc Material |
Organic |
| Disc Quantity |
2 |
| Material |
Billet Steel Flywheel / Nodular Iron Pressure Plate / Segmented Organic Friction |
| Out of Package Weight |
47.30 |
| Title |
PN: 413613099 - DYAD DS 10.4, Clutch and Flywheel Kit |
| Tooth Quantity |
130 |
| Length |
5.5000 |
| Width |
18.0000 |
| Height |
18.0000 |
| Weight |
50.0500 |
