Bilstein F4-BE5-G723-M0 M 9100 (Bump Stop) - Suspension Bump Stop

2 sold in last 8 days
Bilstein
ds_BBGL_F4-BE5-G723-M0
Out of stock
Suspension Bump Stop
$476.51
customers are viewing this product
Bilstein F4-BE5-G723-M0 M 9100 (Bump Stop) - Suspension Bump Stop
Details

Bilstein M 9100 (Bump Stop) is designed to provide a significant increase in compression control over the last few inches of suspension travel on custom off-road applications. M 9100 (Bump Stop) is available in 3 different stroke lengths ranging from 2-4 inch travel that can accommodate a wide range of custom mount configurations. M 9100 (Bump Stop) has a replaceable strike pad for easy maintenance. This bump stop utilizes a nitrogen fill valve which can be used to fully adjust the compression force. When properly applied, M 9100 (Bump Stop) will effectively decelerate the suspension and prevent harsh bottoming on custom off-road applications.

Specifications:

Description_ASM No Applications
Description_DEF Suspension Bump Stop
Description_DES M 9100 (Bump Stop) - Suspension Bump Stop
Description_INV 3" TRAVEL BUMP STOP SHOCK
Description_EXT 46mm Monotube Bump Stop
Description_MKT Bilstein M 9100 (Bump Stop) is designed to provide a significant increase in compression control over the last few inches of suspension travel on custom off-road applications. M 9100 (Bump Stop) is available in 3 different stroke lengths ranging from 2-4 inch travel that can accommodate a wide range of custom mount configurations. M 9100 (Bump Stop) has a replaceable strike pad for easy maintenance. This bump stop utilizes a nitrogen fill valve which can be used to fully adjust the compression force. When properly applied, M 9100 (Bump Stop) will effectively decelerate the suspension and prevent harsh bottoming on custom off-road applications.
Description_LAB M 9100 (Bump Stop) - Suspension Bump Stop
Description_SHO Bump Stop
Reservoir No
Body Diameter (ID) 46mm
Compression @0.52m/s Custom
Optional Reservoir Clamp N/A
Lower Mount Type Special
California Proposition 65 WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Mount Type Special
Finish Nickel Plated
Collapsed Length (MM) 244.1
Title Bilstein Shock Absorbers
Rebound @0.52m/s Custom
Extended Length (MM) 316.7
Series M 9100 (Bump Stop)
Internal Design Monotube
Spring Seat Included No
Extended Length (IN) 12.47
Collapsed Length (IN) Rounded 10
Upper Mount Type Special
Extended Length (IN) Rounded 12
Collapsed Length (IN) 9.61
Body Design Smooth Body (Non-Coilover)
Length 6.0000
Width 6.0000
Height 27.0000
Weight 4.0000
