The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension s SB033 rear sway bar was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-wall 32mm DOM tubing, the SB033 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality.Thrust washers are welded to the bar to locate the sway bar bushing mounts. This is critical as it properly locates the sway bar and prevents lateral movement during hard cornering maneuvers. The SB033 attaches to your Camaro with 88-durometer polyurethane bushings, reducing the deflection from the stock rubber bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keeps grease in the bushing. The fabricated laser cut, TIG-welded steel sway bar end links are reinforced to minimize deflection. The sway bar is 3-way adjustable to tune the amount of torsional spring rate and to determine the handling characteristics (understeer/oversteer) of the vehicle.
Specifications:
| Description_ASC |
Fits all FE4 suspension-equipped Fifth Gen Camaros (2013-2015 SS, 2012-newer ZL1);Designed for street performance, autocross, and road race applications;Dramatically reduces body roll;25%-200% increase is sway bar rate over stock sway bar (depending on year and model);Cold formed to better resist torsional fatigue;Manufactured from 32mm heavy-wall DOM tubing for increased strength;Three-way adjustable for street and track use ;Adjustability allows for fine-tuning of suspension;88-durometer, greasable polyurethane bushing;Zinc-plated inner sleeves;Durable powdercoat finish;1-2-hour installation time;Proudly designed in the U.S.A.;Proudly made in the U.S.A. |
| Description_DEF |
Coil Spring / Tie Rod Sleeve / Stabilizer Bar Kit |
| Description_DES |
Swaybar Kit With Bushings, Rear, Adjustable, Hollow 32mm |
| Description_EXT |
BMR Suspension designed the SB033 sway bar kit for street performance, autocross, and road race applications. |
| Description_INV |
BMR Suspension - SB033H |
| Description_MKT |
The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension?s SB033 rear sway bar was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-wall 32mm DOM tubing, the SB033 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality.Thrust washers are welded to the bar to locate the sway bar bushing mounts. This is critical as it properly locates the sway bar and prevents lateral movement during hard cornering maneuvers. The SB033 attaches to your Camaro with 88-durometer polyurethane bushings, reducing the deflection from the stock rubber bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keeps grease in the bushing. The fabricated laser cut, TIG-welded steel sway bar end links are reinforced to minimize deflection. The sway bar is 3-way adjustable to tune the amount of torsional spring rate and to determine the handling characteristics (understeer/oversteer) of the vehicle. |
| Description_SHO |
Sway Bar Kit |
| Mounting Hardware Included |
Yes |
| Position |
Rear |
| Quantity |
Sold as a kit |
| Rear Sway Bar Adjustable |
3-position |
| Rear Sway Bar Diameter (in) |
1.25 inches |
| Rear Sway Bar Diameter (mm) |
32.0 mm |
| Rear Sway Bar Type |
Hollow |
| Sway Bar Finish |
Black hammertone powdercoated |
| Sway Bar Material |
Steel |
| Length |
66.0000 |
| Width |
14.0000 |
| Height |
5.0000 |
| Weight |
31.0000 |
