Up front, a pair of progressive rate, diesel-specific, 4.5" coil springs provides the extra height and smooth handling in the harshest of terrains. A forged drop pitman arm is supplied to correct steering angles. Polyurethane bump stops limit up-travel, while brake line relocation brackets will allow your suspension to easily reach "full droop". To correct the front suspension geometry at the new height, a pair of heavy-duty replacement radius arms is provided that bolt directly into the factory location. These new arms are massive upgrade to the factory stamped units, built from 1/4" American made steel, and internally gusseted with a lower cam adjustment to dial in front end caster.
Specifications:
| Description_DEF |
Suspension Lift Kit |
| Description_DES |
Zone 4.5" Radius Arm Lift Kit - Diesel |
| Description_MKT |
Up front, a pair of progressive rate, diesel-specific, 4.5" coil springs provides the extra height and smooth handling in the harshest of terrains. A forged drop pitman arm is supplied to correct steering angles. Polyurethane bump stops limit up-travel, while brake line relocation brackets will allow your suspension to easily reach "full droop". To correct the front suspension geometry at the new height, a pair of heavy-duty replacement radius arms is provided that bolt directly into the factory location. These new arms are massive upgrade to the factory stamped units, built from 1/4" American made steel, and internally gusseted with a lower cam adjustment to dial in front end caster. |
| Description_SHO |
4.5" DSL RA Lift Kit |
| Description_LAB |
2019-2022 Ram 2500 4.5" Radius Arm Diesel - 6-Bolt T-Case - FOX Shocks |
| Accommodates Factory Wheels |
Yes |
| Rear Lift Method |
Coil Springs |
| Front Lift Method |
Strut Spacers |
| Requires Metal Cutting |
Yes |
| Rear Lift Height |
2.5" |
| California Proposition 65 |
! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Installation Time |
7-9 hrs |
| Finish |
Powdercoat |
| Back Spacing |
4.5" |
| Max Tire Size 2 |
37 x 12.5 |
| Front Lift Height |
4.5" |
| Max Tire Size |
35 x 12.5 |
| Installation Difficulty |
4 out of 5 |
| Requires Welding |
No |
| Wheel Size |
20 x 9 |
| Material |
Steel |
| Back Spacing 2 |
5.5" |
| Lift Type |
Lift Kit |
| Wheel Size 2 |
20 x 9 |
| Adjustable |
No |
| Required Tools |
Pitman Arm Puller |
| Weight |
243.0000 |
