To properly lift the Colorado/Canyon suspension 5.5", we started with ductile cast iron steering knuckles that reposition critical steering and control arm mounting locations, and work in harmony with the heavy-duty, fabricated crossmembers. Differential drop brackets lower and reposition the front differential for correct CV shaft angles and still allow for use of the factory front driveshaft with the help of a spacer that helps retain optimum CV joint positioning. A full-width differential skid plate protects the relocated differential from the underside and ties the front and rear crossmembers together. Factory struts are retained and relocated with top spacers to gain a full 5.5" of lift without requiring any strut disassembly and that position the struts to eliminate binding through wheel travel. In the rear, a new block and U-bolt kit provided 4" of lift to level out the rear with the front. Extended sway bar links, bump stop extensions, and brake line relocation are also included.
Specifications:
| Description_DEF |
Suspension Lift Kit |
| Description_DES |
Zone 5.5" Suspension Lift kit |
| Description_MKT |
To properly lift the Colorado/Canyon suspension 5.5", we started with ductile cast iron steering knuckles that reposition critical steering and control arm mounting locations, and work in harmony with the heavy-duty, fabricated crossmembers. Differential drop brackets lower and reposition the front differential for correct CV shaft angles and still allow for use of the factory front driveshaft with the help of a spacer that helps retain optimum CV joint positioning. A full-width differential skid plate protects the relocated differential from the underside and ties the front and rear crossmembers together. Factory struts are retained and relocated with top spacers to gain a full 5.5" of lift without requiring any strut disassembly and that position the struts to eliminate binding through wheel travel. In the rear, a new block and U-bolt kit provided 4" of lift to level out the rear with the front. Extended sway bar links, bump stop extensions, and brake line relocation are also included. |
| Description_LAB |
2015-2022 Colorado/Canyon 5.5in Suspension |
| Description_SHO |
5.5" Lift Kit |
| California Proposition 65 |
! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Installation Time |
6-8 hrs |
| Max Tire Size |
305 / 55 |
| Back Spacing 2 |
4.5" |
| Wheel Size 3 |
17 x 8.5 |
| Installation Difficulty |
4 out of 5 |
| Rear Lift Height |
4" |
| Required Tools |
Torx Bit / Socket Set; Cut-off Tool; Wrenches: Standard |
| Back Spacing |
5.25" |
| Lift Type |
Lift Kit |
| Requires Metal Cutting |
No |
| Max Tire Size 3 |
295 / 65 |
| Front Lift Method |
Strut Spacers |
| Finish |
Powdercoat |
| Requires Welding |
No |
| Wheel Size |
20 x 9 |
| Material |
Steel |
| Adjustable |
No |
| Max Tire Size 2 |
295 / 65 |
| Rear Lift Method |
Lift Block |
| Back Spacing 3 |
4.5" |
| Front Lift Height |
5.5" |
| Wheel Size 2 |
18 x 9 |
| Accommodates Factory Wheels |
No |
| Weight |
202.0000 |
