McLeod Racing's 50 years of world class clutch innovation has brought a new line that is inspired from a racing heritage. McLeod Racing introduces a twin disc clutch set up for the street, the Mag Force SE. Rated up to 700 HP, this twin disc clutch is perfect for the high horsepower street cars in both Import and Domestic applications. With a billet aluminum cover, two ceramic discs, this is your ideal clutch for the street or the track.
Specifications:
| Description_ASM |
Chevrolet: Avalanche 07 - 13 5.3 L Engine, Chevrolet: Avalanche 07 - 09 6 L Engine, Chevrolet: Avalanche 1500 06 - 06 5.3 L Engine, Chevrolet: C1500 99 - 99 5.7 L Engine, Chevrolet: C1500 Suburban 99 - 99 5.7 L Engine, Chevrolet: C2500 99 - 00 5.7 L Engine, Chevrolet: C2500 Suburban 99 - 99 5.7 L Engine, Chevrolet: C3500 99 - 00 5.7 L Engine, Chevrolet: Camaro 98 - 02 5.7 L Engine, Chevrolet: Caprice 11 - 14 6 L Engine, Chevrolet: Colorado 09 - 09 5.3 L Engine, Chevrolet: Corvette 97 - 04 5.7 L Engine, Chevrolet: Corvette 05 - 07 6 L Engine, Chevrolet: Corvette 06 - 13 7 L Engine, Chevrolet: Express 1500 07 - 14 5.3 L Engine, Chevrolet: Express 1500 97 - 02 5.7 L Engine, Chevrolet: Express 2500 03 - 14 4.8 L Engine, Chevrolet: Express 2500 97 - 02 5.7 L Engine, Chevrolet: Express 2500 03 - 14 6 L Engine, Chevrolet: Express 3500 05 - 14 4.8 L Engine, Chevrolet: Express 3500 97 - 02 5.7 L Engine, Chevrolet: Express 3500 03 - 14 6 L Engine, Chevrolet: Impala 06 - 09 5.3 L Engine, Chevrolet: K1500 99 - 99 5.7 L Engine, Chevrolet: K1500 Suburban 99 - 99 5.7 L Engine, Chevrolet: K2500 99 - 00 5.7 L Engine, Chevrolet: K2500 Suburban 99 - 99 5.7 L Engine, Chevrolet: K3500 99 - 00 5.7 L Engine, Chevrolet: Monte Carlo 06 - 07 5.3 L Engine, Chevrolet: P30 97 - 99 5.7 L Engine, Chevrolet: Silverado 1500 99 - 13 4.8 L Engine, Chevrolet: Silverado 1500 06 - 14 5.3 L Engine, Chevrolet: Silverado 1500 03 - 13 6 L Engine, Chevrolet: Silverado 1500 HD 01 - 06 6 L Engine, Chevrolet: Silverado 2500 01 - 04 6 L Engine, Chevrolet: Silverado 2500 HD 01 - 14 6 L Engine, Chevrolet: Silverado 3500 01 - 06 6 L Engine, Chevrolet: Silverado 3500 HD 07 - 14 6 L Engine, Chevrolet: Suburban 1500 06 - 14 5.3 L Engine, Chevrolet: Suburban 1500 06 - 09 6 L Engine, Chevrolet: Suburban 2500 01 - 13 6 L Engine, Chevrolet: Tahoe 00 - 09 4.8 L Engine, Chevrolet: Tahoe 06 - 14 5.3 L Engine, Chevrolet: Tahoe 99 - 00 5.7 L Engine, Chevrolet: Tahoe 08 - 13 6 L Engine, Chevrolet: Trailblazer 06 - 09... |
| Description_DEF |
Transmission Clutch Kit |
| Description_DES |
Mag ForceSE: Triple Disc: Pin Drive: Chevrolet:1997-13 LS-X 6 Bolt:168T:1-1/8x26 |
| Description_INV |
Clutch Kit |
| Description_EXT |
Mag ForceSE: Triple Disc: Pin Drive: Chevrolet: 1997-13 LS-X 6 Bolt Crank: 168T:1-1/8x26: Ceramic Discs |
| Description_FAB |
The Mag Force is perfect for Road Racing, Drag Racing and Salt Flats Time trials. |
| Description_SHO |
Clutch Kit |
| Description_MKT |
McLeod Racing's 50 years of world class clutch innovation has brought a new line that is inspired from a racing heritage. McLeod Racing introduces a twin disc clutch set up for the street, the Mag Force SE. Rated up to 700 HP, this twin disc clutch is perfect for the high horsepower street cars in both Import and Domestic applications. With a billet aluminum cover, two ceramic discs, this is your ideal clutch for the street or the track. |
| Disc Diameter |
8In. |
| Flywheel Material |
Aluminum |
| Racing Application |
Road Race & Slalom Racing |
| Flywheel Included |
Yes |
| Hardware Included |
Yes |
| Racing Application 2 |
Drifting |
| Pilot Bushing Included |
No |
| Make |
Chevrolet |
| Racing Application 3 |
Dry Lakes (Bonneville) |
| Alignment Tool Included |
Yes |
| Pilot Bushing Material |
N/A |
| Throwout Bearing Style |
Standard |
| Number of Discs |
Double |
| Throwout Bearing Included |
No |
| Spline |
1 1/8In. x 26 |
| Ring Gear |
168 tooth |
| Engine |
1997-2013 LS 1/2/3/6/7 |
| Engine Balance |
Internal Balance |
| Disc Style |
Segmented |
| Disc Material |
Ceramic Puck |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
28.0000 |
