In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing!
Specifications:
| Description_ASM |
Ford: Mustang 00 - 00 5.4 L Engine, Ford: Mustang 96 - 04 4.6 L Engine |
| Description_DEF |
Transmission Clutch Kit |
| Description_DES |
Original Street Twin: Steel: Ford: 1996-04 4.6L: 8 Bolt Crank: 1-1/8X26: 164T |
| Description_INV |
Clutch Kit |
| Description_FAB |
McLeod Racing is the leader in twin disc clutch applications. We offer them in several different configurations to meet your needs. Give us a call 714-630-2764 to see what we can do for you! |
| Description_MKT |
In 1974 With The Rising Popularity Of Power Adders Such As Nitrous,Superchargers And Turbochargers, Mcleod Recognized The Need For A Clutch Assembly That Was Street Friendly, Yet Still Capable Of Handling Up To 1,200 Horsepower, Thus The Street Twin Was Born! This Series Of Mcleod Clutch Kit Is Intended For High Horsepower Street Enthusiast. Whether It'S Nos,Supercharger,Turbocharger Or A Big Inch Mountain Motor The "Original Street Twin" Can Handle It. Go With The Innovator Not The Imitator Mcleod Racing! |
| Description_SHO |
Clutch Kit |
| Description_EXT |
Original Street Twin: Steel: Ford: 1996-04 4.6L: 8 Bolt Crank: 1-1/8X26: 164T |
| Disc Material |
Ceramic |
| Throwout Bearing Style |
Standard Mechanical |
| Number of Discs |
Double |
| Alignment Tool Included |
Yes |
| Pilot Bushing Included |
No |
| Spline |
1-1/8 x 26 |
| Pressure Plate Style |
Diaphragm |
| Engine |
Modular Ford 4.6L/5.0L/5.4L 8 Bolt Crank |
| Ring Gear |
164 |
| Engine Balance |
Neutral |
| Flywheel Material |
Steel |
| NOTE: |
This unit is intended for aftermarket transmission. For more info call McLeod Tech at 714-630-2764 |
| Pilot Bushing Material |
N/A |
| Horsepower Rating |
1500 |
| Hub Style |
Solid |
| Disc Style |
Segmented |
| Make |
Ford |
| Additional Counter Weight Kit Required |
N/A |
| Clutch Usage |
Street |
| Disc Diameter |
10.5In. |
| Hardware Included |
Yes |
| Flywheel Included |
Yes |
| Throwout Bearing Included |
No |
| Clutch Patterns |
Street Twin Pattern |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
50.0000 |
