Fog Beam- Provides a low, wide angle light pattern that increases short-range visibility in conditions like dust, fog, snow and rain. KC's Innovative adjustable mount allows users to easily adjust the aiming of lights horizontally for an optimum and consistent beam angle. KC's OE mounting system bolts directly up to the Jeep JK OE bumper and OE fog light harness.Fog Beam Pattern (SAE ECE Street Legal)Lux at 10 Meters: 150 lx Constructed from a lightweight military-grade (US MIL-810-STD) IP67 rated sealed Aluminum Die-Cast Housing with shatterproof GE(R) Lexan lens for an impenetrable, waterproof housing. The C2 flood light was built to last, utilizing advanced Dual Heat-Sink design for maximum heat dissipation to ensure optimum light performance for up to 50,000 hours.
Specifications:
| Description_ASM |
2010-2018 Jeep Wrangler JK |
| Description_DEF |
Fog Light |
| Description_DES |
KC G4 Gravity LED 4in SAE ECE Fog 1-Light 2010-2018 Jeep Wrangler JK |
| Description_EXT |
KC HiLiTES 1497 4 in Gravity LED Fog Light feature bright CREE LEDs in a street legal fog beam pattern. Sealed magnesium housing and shatter proof polycarbonate lens, with universal adjustable bracket for easy OE mounting on 10-18 Jeep JKs. |
| Description_INV |
KC Gravity LED |
| Description_MKT |
Fog Beam- Provides a low, wide angle light pattern that increases short-range visibility in conditions like dust, fog, snow and rain. KC's Innovative adjustable mount allows users to easily adjust the aiming of lights horizontally for an optimum and consistent beam angle. KC's OE mounting system bolts directly up to the Jeep JK OE bumper and OE fog light harness.Fog Beam Pattern (SAE ECE Street Legal)Lux at 10 Meters: 150 lx Constructed from a lightweight military-grade (US MIL-810-STD) IP67 rated sealed Aluminum Die-Cast Housing with shatterproof GE(R) Lexan lens for an impenetrable, waterproof housing. The C2 flood light was built to last, utilizing advanced Dual Heat-Sink design for maximum heat dissipation to ensure optimum light performance for up to 50,000 hours. |
| Description_FAB |
Clear LED |
| Description_FAB |
Constructed from an IP68 rated magnesium housing and polycarbonate lens creating a fully self contained LED light housing. |
| Description_FAB |
Fog Beam Pattern (SAE ECE Street Legal) |
| Description_FAB |
Street Legal 10-18 Jeep JK Application |
| Description_FAB |
Lightweight Magnesium Housing for Maximum Heat Dissipation |
| Description_SHO |
Fog Light |
| Compliance |
SAE J583 ECE-R19 Street Legal |
| Prop 65 Yes/No |
No |
| Voltage |
9V-32V |
| Lux at 10 Meters |
150 lx |
| Product Dimensions |
W 3.94 in x H 3.94 in x D 3.44 in |
| LED Source |
CREE LED |
| Candela |
150,000 cd |
| Wattage |
10W |
| Add-On |
N/A |
| Lux at 10 Meters |
150 lx |
| Beam Pattern |
Fog |
| Light Temp |
5000K |
| Beam Distance (Meters) |
245m |
| Lumens |
866 |
| Title |
KC Hilites 4 in Gravity LED G4 - Single Light - SAE/ECE - 10W Fog Beam - for 10-18 Jeep JK |
| IP Rating |
IP68 |
| Raw Lumens |
866 lm |
| Color Temperature |
5000K |
| Lux |
150 |
| Amp Draw |
.74A |
| Length |
6.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
