Hard launches from high horsepower cars at the drag strip require more than just a normal street-style sway bar. BMR Suspension s Xtreme Anti Roll Bar for 2005-2014 Mustang or 2007-2014 Shelby GT500 allows you to launch harder without excessive body roll limiting traction, with little sacrifice to your Mustang s street manners. Manufactured from heavy-wall 1.375-inch DOM tubing, BMR s Xtreme Anti Roll Bar (XSB005) is designed to eliminate body roll and transfer as much power as possible to the rear wheels. The XSB005 attaches to your Mustang with polyurethane bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keep grease in the bushing under high compression loads. The fabricated laser cut, steel sway bar arms are reinforced to add strength and minimize deflection.
Specifications:
| Description_ASC |
Fits all 2005-2014 Mustangs and 2007-2014 Shelby GT500s;Designed for street performance and drag race applications;Dramatically reduces body roll;Up to 4,090% increase is sway bar rate over stock sway bar (depending on year and model);Cold formed to better resist torsional fatigue;Manufactured from 1.375-inch heavy-wall DOM tubing for increased strength;Three-way adjustable for limited street and track use ;Adjustability allows for fine-tuning of suspension;88-durometer, greasable polyurethane bushings;Durable powdercoat finish;1-2-hour installation time;Proudly designed in the U.S.A.;Proudly made in the U.S.A. |
| Description_DEF |
Coil Spring / Tie Rod Sleeve / Stabilizer Bar Kit |
| Description_DES |
Xtreme Anti-roll Bar Kit, Rear, Hollow 35mm |
| Description_EXT |
BMR Suspension designed the XSB005 anti-roll bar for drag race and limited street applications. |
| Description_INV |
BMR Suspension - XSB005H |
| Description_MKT |
Hard launches from high horsepower cars at the drag strip require more than just a normal street-style sway bar. BMR Suspension?s Xtreme Anti Roll Bar for 2005-2014 Mustang or 2007-2014 Shelby GT500 allows you to launch harder without excessive body roll limiting traction, with little sacrifice to your Mustang?s street manners. Manufactured from heavy-wall 1.375-inch DOM tubing, BMR?s Xtreme Anti Roll Bar (XSB005) is designed to eliminate body roll and transfer as much power as possible to the rear wheels. The XSB005 attaches to your Mustang with polyurethane bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keep grease in the bushing under high compression loads. The fabricated laser cut, steel sway bar arms are reinforced to add strength and minimize deflection. |
| Description_SHO |
Anti-roll Bar Kit |
| Mounting Hardware Included |
Yes |
| Notes |
Includes billet sway bar saddles |
| Position |
Rear |
| Quantity |
Sold as a kit |
| Rear Sway Bar Adjustable |
3-position |
| Rear Sway Bar Diameter (in) |
1.375 inches |
| Rear Sway Bar Diameter (mm) |
35.0 mm |
| Rear Sway Bar Type |
Hollow |
| Sway Bar Finish |
Red powdercoated |
| Sway Bar Material |
Steel |
| Length |
49.0000 |
| Width |
13.0000 |
| Height |
13.0000 |
| Weight |
29.0000 |
