| Description_ASM |
2004-2005 Cadillac CTS 5.7 Liter, 2006 Cadillac CTS 6.0 Liter, 2002-2005 Cadillac Escalade 5.3 Liter, 2002-2006 Cadillac Escalade 6.0 Liter, 2002-2006 Cadillac Escalade EXT 6.0 Liter, 2005-2010 Cadillac STS 4.6 Liter, 2004-2009 Cadillac XLR 4.6 Liter |
| Description_DEF |
Engine Oil Filter Remote Mounting Kit |
| Description_DES |
Single Remote Oil Filter System; 2-1/2 in. ID; 2-3/4 in. OD Flange; 13/16 in.-16 |
| Description_EXT |
Single Oil Filter Relocation System; 2-1/2 in. I.D. and 2-3/4 in. O.D. Bypass Flange w/ 13/16 in.-16 Threads |
| Description_INV |
TRANS-DAPT OIL FILTER RELOCATION KIT |
| Description_SHO |
OIL RELOCATION KIT |
| Additional Details |
Uses Trans-Dapt #1156 Compact oil filter, Fram PH8A, or equivalent filter. |
| California Proposition 65 |
WARNING: Cancer & Reproductive Harm. For more info visit www.P65Warnings.ca.gov |
| Bolt Hole Quantity |
3 |
| Contents |
Oil Filter Bypass Adapter, remote single oil filter base, 2- 30 in. hoses, 4 brass fittings, mounting Hardware & instructions. |
| Filter Bypass Style |
Standard Port Filter Bypass |
| Filter Nipple Thread Size |
13/16 in.-16 |
| Fitting Material |
Brass |
| Materials |
Cast Aluminum |
| Hose Bust Pressure |
1200 psi |
| Fitting Quantity |
4 |
| Hose Connection Type |
Push Lock |
| Material |
Cast Aluminum |
| Hose ID |
1/2 in. |
| Hose Material |
Flame Resistant Nitrile/Rubber |
| Fitting Finish |
Raw |
| Notes |
Single Oil Filter Relocation System; 2-1/2 in. I.D. and 2-3/4 in. O.D. Bypass Flange w/ 13/16 in.-16 Threads |
| Kit Type |
Single Filter Kits |
| Fitting Thread |
1/2 in. NPT |
| Hose Type |
Reinforced 1 Fiber Band |
| Fitting Type |
Hose Barb |
| Hose OD |
3/4 in. |
| IMPORTANT! |
NOT FOR DIESEL, MARINE OR RACE USE! See HAMBURGER'S Billet Filtration Components |
| Hose Length |
30 in. |
| Mount Material |
Cast Aluminum |
| Hose Thickness |
0.125 in. |
| Hose Temperature Range |
-40 F to +212 F |
| Oil Filter Compatibility |
FRAM PH8A, Trans-Dapt 1156 or Equivalent |
| O.E. Replacement |
No |
| VEHICLE Oil Filter Nipple Size |
13/16 in.-16 |
| Package Contents |
Oil Filter Bypass Adapter, remote oil filter base, 2 hoses, 4 fittings, 4 hose ferrules mounting Hardware |
| Port Size |
1/2 in. NPT |
| Product Details |
Fits engine blocks designed to accept oil filters with a 13/16 in.-16 thread and 2-5/8 in. diameter sealing o-ring. |
| Remote Base Filter Size |
PH8A (or equivalent) |
| Race Only |
No |
| VEHICLE Oil Filter Flange OD |
2-3/4 in. |
| VEHICLE Oil Filter Flange ID |
2-1/2 in. |
| Port Style |
Vertical |
| Performance |
Yes |
| Title |
TRANS-DAPT PERFORMANCE PRODUCTS SINGLE OIL FILTER RELOCATION SYSTEM; 2-1/2 IN. I.D. AND 2-3/4 IN. O.D. BYPASS FLANGE W/ 13/16 IN.-16 THREADS |
| Vehicle Specific Listings |
Please refer to application chart pdf files for vehicle specific listings. |
| Single or Dual Filter |
Single |
| Length |
4.0000 |
| Width |
8.0000 |
| Height |
12.0000 |
| Weight |
3.0000 |
