K&N premium oil filters are meticulously engineered to offer outstanding filtration and engine protection. Designed to operate with all synthetic, conventional, and blended motor oils, K&N's pleated synthetic-blend filtration media helps to shield your engine from contaminants and ensure a consistent flow of oil. The heavy-duty canister is engineered to be exceptionally durable, and a one-inch welded hex nut can be used for quick and easy filter removal. Each filter is specifically designed to withstand the service intervals recommended by vehicle manufacturers, and is protected by the K&N 1-Year Limited Warranty.
Specifications:
Description_DEF |
Engine Oil Filter |
Description_EXT |
K&N Wrench-Off oil filters are engineered to help ensure high flow rates and exceptional protection from contaminants. Each filter comes with a hex nut welded to the top of the canister, allowing for easy removal with a standard wrench. |
Description_DES |
Oil Filter |
Description_MKT |
K&N premium oil filters are meticulously engineered to offer outstanding filtration and engine protection. Designed to operate with all synthetic, conventional, and blended motor oils, K&N's pleated synthetic-blend filtration media helps to shield your engine from contaminants and ensure a consistent flow of oil. The heavy-duty canister is engineered to be exceptionally durable, and a one-inch welded hex nut can be used for quick and easy filter removal. Each filter is specifically designed to withstand the service intervals recommended by vehicle manufacturers, and is protected by the K&N 1-Year Limited Warranty. |
Description_INV |
Oil Filter |
Description_SHO |
Oil Filter |
Package Material |
Paperboard |
Prop 65 Yes/No |
No |
Thread Specification |
M20 X 1.5-6H |
Gasket Material |
High Temperature Nitrile |
Anti Drain Back Valve |
Yes |
Bypass Valve |
Yes |
PSI Relief Valve |
11-17 |
Package Type |
Box |
Height |
3.406 in (87 mm) |
Removal Nut Size |
1 inch |
Weight |
0.8 lb (0.3 kg) |
Removal Nut |
Yes |
Style |
Spin-On |
Product Style |
Oil Filters |
Filter Material |
High Flow Premium Media |
Title |
K&N HP-1004 Oil Filter |
Outside Diameter |
3.156 in (80 mm) |
Warranty |
1 Year Limited |
Length |
4.0000 |
Width |
3.0000 |
Height |
3.0000 |
Weight |
1.0000 |
