SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet LS |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 4.065 Bore, 1.050 CD, 0.927 Pin Dia, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet LS, 4.065 Bore, Flat Top, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Piston Series |
SRP Pro 4032 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Piston Pin Outside Diameter |
0.927 |
| Piston Volume |
-5.00 |
| Piston Pin Wall Thickness |
0.170 |
| Compression Height |
1.050 |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Wrist Pin Wall Thickness |
0.170 |
| Title |
SRP Pro 4032 - Chevrolet, LS Gen III/IV, 4.065 in. Bore, Piston Kit |
| Make |
CHEVROLET |
| Bore Diameter |
4.065 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Prop 65 (C, R or CR) |
CR |
| Product Market |
Domestic |
| Make - Web |
Chevrolet |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
LS Gen III/IV |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Out of Stock Message |
Call for Availibility |
| Engine |
LS Gen III/IV |
| Piston Head Type |
Flat Top |
| Piston Pin Length |
2.250 |
| Title - Web |
SRP Pro 4032 Chevrolet LS Gen III/IV Piston Kit - 4.065 in. Bore - 1.050 in. CH, -5.00 CC |
| Add-On |
927-2250-17-51C |
| Industry |
Automotive |
| Length |
1.0000 |
| Width |
1.0000 |
| Height |
1.0000 |
| Weight |
13.0000 |
