Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.375 Bore, 1.485 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.375 in. Bore, 1.485 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.375 Bore, Dish, Set of 8 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Wrist Pin Length |
2.930 |
| Piston Volume |
-24.00 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
990-2930-18-51S |
| Industry |
Automotive |
| Cylinder Head |
440 WEDGE |
| Add-On |
990-042-CS |
| Add-On |
S100S8-4375-5 |
| Ring Set Included |
No |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
4032 |
| Product Type |
Engine Piston Kit |
| Make - Web |
Chrysler |
| Piston Pin Length |
2.930 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.375 in. Bore - 1.485 in. CH, -24.00 CC |
| Oil Ring Thickness |
0.188 |
| Bore Diameter |
4.375 |
| Second Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
No |
| Engine |
Big Block |
| Out of Stock Message |
Call for Availability |
| Compression Height |
1.485 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Series |
SRP |
| Piston Pin Outside Diameter |
0.990 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Head Type |
Dish |
| Piston Average Weight |
608 |
| Product Market |
Domestic |
| Make |
CHRYSLER |
| Title |
SRP - Chrysler, Big Block, 4.375 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
