Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.350 Bore, 1.485 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.350 in. Bore, 1.485 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.350 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Piston Average Weight |
602 |
| Make |
CHRYSLER |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Outside Diameter |
0.990 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.180 |
| Compression Height |
1.485 |
| Wrist Pin Outer Diameter |
0.990 |
| Out of Stock Message |
Call for Availability |
| Piston Material |
4032 |
| Bore Diameter |
4.350 |
| Title |
SRP - Chrysler, Big Block, 4.350 in. Bore, Piston Kit |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-24.00 |
| Industry |
Automotive |
| Piston Pin Length |
2.930 |
| Oil Ring Thickness |
0.188 |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Cylinder Head |
440 WEDGE |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.180 |
| Make - Web |
Chrysler |
| Engine - Web |
Big Block |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Prop 65 Yes/No |
Yes |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.350 in. Bore - 1.485 in. CH, -24.00 CC |
| Add-On |
S100S8-4350-5 |
| Add-On |
990-2930-18-51S |
| Piston Series |
SRP |
| Engine |
Big Block |
| Add-On |
990-042-CS |
| Piston Head Type |
Dish |
| Ringset Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
