Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.375 Bore, 1.815 CD, 0.990 Pin, Set of 8. |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.375 in. Bore, 1.815 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Chrysler 440, 4.375 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.180 |
| Bore Diameter |
4.375 |
| Piston Pin Outside Diameter |
0.990 |
| Engine - Web |
Big Block |
| Product Market |
Domestic |
| Compression Height |
1.815 |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.990 |
| Title |
SRP - Chrysler, Big Block, 4.375 in. Bore, Piston Kit |
| Piston Volume |
-24.00 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.188 |
| Make |
CHRYSLER |
| Top Compression Ring Thickness |
0.0640 |
| Second Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Piston Pin Material |
5115 |
| Piston Series |
SRP |
| Piston Material |
4032 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Average Weight |
692 |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Add-On |
990-2930-18-51S |
| Industry |
Automotive |
| Add-On |
990-042-CS |
| Ringset Included |
No |
| Engine |
Big Block |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.375 in. Bore - 1.815 in. CH, -24.00 CC |
| Piston Pin Length |
2.930 |
| Piston Head Type |
Dish |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
440 WEDGE |
| Add-On |
S100S8-4375-5 |
| Prop 65 Yes/No |
Yes |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
