Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.360 Bore, 1.815 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.360 in. Bore, 1.815 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.360 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Piston Series |
SRP |
| Top Compression Ring Thickness |
0.0640 |
| Compression Height |
1.815 |
| Ringset Included |
No |
| Piston Average Weight |
685 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Engine - Web |
Big Block |
| Oil Ring Thickness |
0.188 |
| Piston Pin Outside Diameter |
0.990 |
| Piston Head Type |
Dish |
| Title |
SRP - Chrysler, Big Block, 4.360 in. Bore, Piston Kit |
| Bore Diameter |
4.360 |
| Wrist Pin Outer Diameter |
0.990 |
| Ring Set Included |
No |
| Add-On |
S100S8-4360-5 |
| Product Type |
Engine Piston Kit |
| Engine Type |
ICE |
| Second Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.360 in. Bore - 1.815 in. CH, -24.00 CC |
| Forging Type |
FSR |
| Piston Volume |
-24.00 |
| Industry |
Automotive |
| Cylinder Head |
440 WEDGE |
| Piston Material |
4032 |
| Add-On |
990-2930-18-51S |
| Make |
CHRYSLER |
| Add-On |
990-042-CS |
| Wrist Pin Length |
2.930 |
| Piston Pin Length |
2.930 |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Engine |
Big Block |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chrysler |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
