Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.375 Bore, 1.485 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.375 in. Bore, 1.485 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.375 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Piston Pin Material |
5115 |
| Engine - Web |
Big Block |
| Make |
CHRYSLER |
| Title |
SRP - Chrysler, Big Block, 4.375 in. Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0640 |
| Piston Series |
SRP |
| Piston Head Type |
Flat |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Compression Height |
1.485 |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.990 |
| Piston Pin Wall Thickness |
0.180 |
| Add-On |
990-2930-18-51S |
| Piston Material |
4032 |
| Add-On |
990-042-CS |
| Industry |
Automotive |
| Bore Diameter |
4.375 |
| Oil Ring Thickness |
0.188 |
| Product Type |
Engine Piston Kit |
| Add-On |
S100S8-4375-5 |
| Piston Pin Outside Diameter |
0.990 |
| Engine Type |
ICE |
| Piston Volume |
-6.00 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Length |
2.930 |
| Engine |
Big Block |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.930 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.375 in. Bore - 1.485 in. CH, -6.00 CC |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
440 WEDGE |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
