Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 383 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.310 Bore, 1.320 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.310 in. Bore, 1.320 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 383 B Series, 4.310 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Compression Height |
1.320 |
| Industry |
Automotive |
| Piston Material |
4032 |
| Top Compression Ring Thickness |
0.0640 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.310 |
| Product Market |
Domestic |
| Engine - Web |
Big Block |
| Add-On |
990-042-CS |
| Product Type |
Engine Piston Kit |
| Add-On |
S100S8-4310-5 |
| Title |
SRP - Chrysler, Big Block, 4.310 in. Bore, Piston Kit |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.990 |
| Add-On |
990-2930-15-51S |
| Cylinder Head |
440 WEDGE |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 Yes/No |
Yes |
| Make |
CHRYSLER |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.310 in. Bore - 1.320 in. CH, -6.00 CC |
| Piston Volume |
-6.00 |
| Wrist Pin Length |
2.930 |
| Wrist Pin Outer Diameter |
0.990 |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
No |
| Piston Series |
SRP |
| Piston Head Type |
Flat |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.218 |
| Piston Pin Wall Thickness |
0.150 |
| Engine |
Big Block |
| Piston Pin Length |
2.930 |
| Piston Pin Material |
5115 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
