As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 1.4L TFSI 2005+ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.051 Bore, 1.141 CD, 0.748 Pin, Set of 4. |
| Description_EXT |
JE, VW, 1.4L TFSI - 2005+, 3.051 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Volkswagen 1.4L TFSI, 3.051 Bore, Dish, Set of 4 |
| Piston Pin Outside Diameter |
0.748 |
| Bore Diameter |
3.051 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Volume |
-8.00 |
| Industry |
Automotive |
| Add-On |
JG1001-3051 |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
748-050-MW |
| Product Market |
European |
| Add-On |
748-2050-16-93C |
| Title |
JE Pistons - Volkswagen, 1.4L TFSI, 3.051 in. Bore, Piston Kit |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
4-VALVE |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Ring Set Included |
Yes |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Wrist Pin Length |
2.050 |
| Engine |
1.4L TFSI 2005+ |
| Piston Quantity |
4 |
| Piston Pin Wall Thickness |
0.160 |
| Piston Pin Length |
2.050 |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Compression Height |
1.141 |
| Engine Detail |
1.4L TFSI 2005+ |
| Engine - Web |
1.4L TFSI |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Volkswagen |
| Piston Pin Material |
9310 |
| Engine Type |
ICE |
| Title - Web |
JE Pistons Volkswagen 1.4L TFSI Piston Kit - 3.051 in. Bore - 1.141 in. CH, -8.00 CC |
| Piston Head Type |
Dish |
| Make |
VOLKSWAGEN |
| Forging Type |
Round |
| Piston Series |
JE Pistons |
| Wrist Pin Outer Diameter |
0.748 |
| Wrist Pin Wall Thickness |
0.160 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
