As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ferrari 3.0L 250 V12 2V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 2.913 Bore, 1.138 CD, 0.669 Pin, Set of 12. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_EXT |
JE, Ferrari, 3.0L 250 V12 2V, 2.913 in. Bore, 9.50:1, Dome, 1 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Ferrari 3.0L 250 V12 2V, 74.00 Bore, Dome, Set of 12 |
| Description_SHO |
Piston Kit |
| Piston Pin Wall Thickness |
0.120 |
| Engine - Web |
3.0L 250 V12 2V |
| Product Market |
European |
| Compression Height |
1.138 |
| Make |
FERRARI |
| Piston Quantity |
2 |
| Piston Pin Outside Diameter |
0.669 |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Wall Thickness |
0.120 |
| Bore Diameter |
74.00 |
| Piston Average Weight |
238 |
| Cylinder Head |
250 SYMMETRICAL |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
9.80 |
| Title |
JE Pistons - Ferrari, 3.0L 250 V12 2V, 74.00 mm Bore, Piston Kit |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.669 |
| Add-On |
669-2250-12-51C |
| Title - Web |
JE Pistons Ferrari 3.0L 250 V12 2V Piston Kit - 74.00 mm Bore - 1.138 in. CH, 9.80 CC |
| Add-On |
XC7400 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Piston Head Type |
Dome |
| Add-On |
669-050-MW |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
3.0L 250 V12 2V |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ferrari |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Forging Type |
Round |
| Piston Pin Length |
2.250 |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
11.0000 |
