As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ferrari 2.4L 246 V6 2V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.701 Bore, 1.181 CD, 0.787 Pin, Set of 6. |
| Description_EXT |
JE, Ferrari, 2.4L 246 V6 2V, 3.701 in. Bore, 9.00:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Ferrari 2.4L 246 V6 2V, 94.00 Bore, Dome, Set of 6 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Cylinder Head |
246 DINO |
| Title |
JE Pistons - Ferrari, 2.4L 246 V6 2V, 94.00 mm Bore, Piston Kit |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
12.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.500 |
| Piston Quantity |
6 |
| Add-On |
787-050-MW |
| Industry |
Automotive |
| Compression Height |
1.181 |
| Add-On |
JG1001-3701 |
| Product Market |
European |
| Bore Diameter |
94.00 |
| Piston Average Weight |
404 |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Piston Pin Outside Diameter |
0.787 |
| Add-On |
787-2500-14-51C |
| Engine - Web |
2.4L 246 V6 2V |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 (C, R or CR) |
CR |
| Title - Web |
JE Pistons Ferrari 2.4L 246 V6 2V Piston Kit - 94.00 mm Bore - 1.181 in. CH, 12.00 CC |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Make |
FERRARI |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ferrari |
| Engine |
2.4L 246 V6 2V |
| Forging Type |
Round |
| Piston Pin Material |
5115 |
| Engine Type |
ICE |
| Piston Pin Length |
2.500 |
| Piston Pin Wall Thickness |
0.140 |
| Oil Ring Thickness |
0.111 |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.787 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
10.0000 |
