As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW 335i Base United States N54B30 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.346 Bore, 1.244 CD, 0.866 Pin, Set of 6. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, BMW, N54B30, 3.346 in. Bore, 9.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
BMW N54B30 3.0L, 85.00 Bore, Dish, Set of 6 |
| Description_SHO |
Piston Kit |
| Wrist Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Ring Set Included |
Yes |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-22.70 |
| Piston Quantity |
6 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Material |
2618 |
| Prop 65 Yes/No |
Yes |
| Make - Web |
BMW |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Add-On |
866-063-MW |
| Bore Diameter |
85.00 |
| Piston Pin Material |
5115 |
| Out of Stock Message |
Call for Availability |
| Engine |
N54B30 |
| Title - Web |
JE Pistons BMW N54B30 Piston Kit - 85.00 mm Bore - 1.244 in. CH, -22.70 CC |
| Industry |
Automotive |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Add-On |
866-2250-18-51C |
| Prop 65 (C, R or CR) |
CR |
| Title |
JE Pistons - BMW, N54B30, 85.00 mm Bore, Piston Kit |
| Cylinder Head |
N54B30 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Add-On |
JG1001-3346 |
| Ringset Included |
Yes |
| Piston Head Type |
Dish |
| Engine Type |
ICE |
| Make |
BMW |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Length |
2.250 |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.244 |
| Piston Pin Outside Diameter |
0.866 |
| Engine - Web |
N54B30 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
