As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
BMW M3 S50B30 EURO |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.396 Bore, 1.245 CD, 0.827 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, BMW, S50B30 Euro, 3.396 in. Bore, 12.50:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
BMW S50B30 3.0L, 86.25 Bore, Dome, Set of 6 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Title - Web |
JE Pistons BMW S50B30 Euro Piston Kit - 86.25 mm Bore - 1.245 in. CH, -3.40 CC |
| Out of Stock Message |
Call for Availability |
| Make - Web |
BMW |
| Ringset Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Bore Diameter |
86.25 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Cylinder Head |
S50B30 EURO |
| Oil Ring Thickness |
0.111 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Material |
2618 |
| Piston Series |
JE Pistons |
| Title |
JE Pistons - BMW, S50B30 Euro, 86.25 mm Bore, Piston Kit |
| Piston Head Type |
Dome |
| Piston Pin Length |
2.250 |
| Piston Volume |
-3.40 |
| Piston Quantity |
6 |
| Engine |
S50B30 EURO |
| Industry |
Automotive |
| Engine - Web |
S50B30 Euro |
| Product Market |
European |
| Product Type |
Engine Piston Kit |
| Add-On |
827-2250-15-51C |
| Add-On |
JG1001-3396 |
| Compression Height |
1.245 |
| Make |
BMW |
| Add-On |
827-063-MW |
| Piston Pin Outside Diameter |
0.827 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Wrist Pin Outer Diameter |
0.827 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.250 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
7.0000 |
