As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan RB25DET |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.406 Bore, 1.220 CD, 0.827 Pin, Set of 6. |
| Description_EXT |
JE, Nissan, RB Series, 3.406 in. Bore, 8.50:1, Dome, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan RB25DET, 86.50 Bore, Dome, Set of 6 |
| Piston Pin Outside Diameter |
0.827 |
| Bore Diameter |
86.50 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Piston Volume |
15.00 |
| Prop 65 Yes/No |
Yes |
| Product Market |
Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Add-On |
827-063-MW |
| Cylinder Head |
4-VALVE |
| Add-On |
827-2250-15-51C |
| Piston Material |
2618 |
| Title |
JE Pistons - Nissan, RB Series, 86.50 mm Bore, Piston Kit |
| Add-On |
JG1001-3405 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
Yes |
| Engine |
RB SERIES |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.250 |
| Prop 65 (C, R or CR) |
CR |
| Compression Height |
1.220 |
| Second Compression Ring Thickness |
0.0480 |
| Piston Quantity |
6 |
| Engine - Web |
RB Series |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Make - Web |
Nissan |
| Title - Web |
JE Pistons Nissan RB Series Piston Kit - 86.50 mm Bore - 1.220 in. CH, 15.00 CC |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Make |
NISSAN |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.111 |
| Wrist Pin Outer Diameter |
0.827 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
5.0000 |
