As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Hyundai 1.6L Gamma Turbo GDI |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.051 Bore, 1.099 CD, 0.787 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Hyundai, 1.6L Gamma Turbo GDI, 3.051 in. Bore, 9.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Hyundai 1.6L Gamma Turbo GDI, 77.50 Bore, Dish, Set of 4 |
| Second Compression Ring Thickness |
0.0480 |
| Make - Web |
Hyundai |
| Piston Head Type |
Dish |
| Engine |
1.6L GAMMA TURBO GDI |
| Piston Series |
JE Pistons |
| Ringset Included |
Yes |
| Title - Web |
JE Pistons Hyundai 1.6L Gamma Turbo GDI Piston Kit - 77.50 mm Bore - 1.099 in. CH, -8.70 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Forging Type |
Round |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Material |
5115 |
| Title |
JE Pistons - Hyundai, 1.6L Gamma Turbo GDI, 77.50 mm Bore, Piston Kit |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Bore Diameter |
77.50 |
| Piston Pin Length |
2.250 |
| Cylinder Head |
GAMMA GDI 1.6T |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Piston Quantity |
4 |
| Piston Pin Wall Thickness |
0.180 |
| Wrist Pin Wall Thickness |
0.180 |
| Prop 65 (C, R or CR) |
CR |
| Compression Height |
1.099 |
| Make |
HYUNDAI |
| Piston Material |
2618 |
| Add-On |
787-2250-18-51C |
| Industry |
Automotive |
| Piston Average Weight |
249 |
| Add-On |
787-050-MW |
| Piston Pin Outside Diameter |
0.787 |
| Prop 65 Yes/No |
Yes |
| Product Type |
Engine Piston Kit |
| Add-On |
JG1001-3051 |
| Piston Volume |
-8.70 |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Outer Diameter |
0.787 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Engine - Web |
1.6L Gamma Turbo GDI |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
