As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K24 with K20A Head |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.504 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Honda, K Series, 3.504 in. Bore, 12.50:1, Dome, 4 Cyl. Piston Kit |
| Description_TLE |
Honda K24, 89.00 Bore, Dome, Set of 4 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Make - Web |
Honda |
| Second Compression Ring Thickness |
0.0480 |
| Cylinder Head |
K20 |
| Ringset Included |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
2618 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Product Type |
Engine Piston Kit |
| Piston Pin Wall Thickness |
0.180 |
| Engine Type |
ICE |
| Add-On |
866-2250-18-51C |
| Out of Stock Message |
Call for Availability |
| Engine |
K SERIES |
| Piston Series |
JE Pistons |
| Industry |
Automotive |
| Add-On |
866-063-MW |
| Title - Web |
JE Pistons Honda K Series Piston Kit - 89.00 mm Bore - 1.176 in. CH, 3.00 CC |
| Add-On |
JG1001-3504 |
| Piston Head Type |
Dome |
| Piston Quantity |
4 |
| Wrist Pin Wall Thickness |
0.180 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Make |
HONDA |
| Product Market |
Sport Compact |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Compression Height |
1.176 |
| Oil Ring Thickness |
0.111 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.866 |
| Title |
JE Pistons - Honda, K Series, 89.00 mm Bore, Piston Kit |
| Piston Volume |
3.00 |
| Bore Diameter |
89.00 |
| Engine - Web |
K Series |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
