As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K24 with K20A Head |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.445 Bore, 1.176 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Honda, K Series, 3.445 in. Bore, 12.50:1, Dome, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda K24, 87.50 Bore, Dome, Set of 4 |
| Engine |
K SERIES |
| Piston Series |
JE Pistons |
| Product Market |
Sport Compact |
| Ringset Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.180 |
| Title |
JE Pistons - Honda, K Series, 87.50 mm Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.866 |
| Cylinder Head |
K20 |
| Make |
HONDA |
| Piston Material |
2618 |
| Piston Pin Outside Diameter |
0.866 |
| Product Type |
Engine Piston Kit |
| Oil Ring Thickness |
0.111 |
| Piston Head Type |
Dome |
| Second Compression Ring Thickness |
0.0480 |
| Engine Type |
ICE |
| Compression Height |
1.176 |
| Industry |
Automotive |
| Piston Quantity |
4 |
| Piston Volume |
4.60 |
| Make - Web |
Honda |
| Engine - Web |
K Series |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Add-On |
866-2250-18-51C |
| Title - Web |
JE Pistons Honda K Series Piston Kit - 87.50 mm Bore - 1.176 in. CH, 4.60 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Bore Diameter |
87.50 |
| Out of Stock Message |
Call for Availability |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3445 |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0400 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
