As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 3.5L Ecoboost Gen II V6 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.661 Bore, 1.240 CD, 0.905 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 2 V6, 3.661 in. Bore, 10.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 3.5L Eco Boost V6, 93.00 Bore, Dish, Set of 6 |
| Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 2 V6 Piston Kit - 93.00 mm Bore - 1.240 in. CH, -9.70 CC |
| Piston Series |
JE Pistons |
| Ringset Included |
Yes |
| Make |
FORD |
| Engine |
3.5L ECOBOOST GEN 2 V6 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.905 |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Outside Diameter |
0.905 |
| Piston Quantity |
6 |
| Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 2 V6, 93.00 mm Bore, Piston Kit |
| Piston Pin Length |
2.250 |
| Piston Material |
2618 |
| Piston Pin Wall Thickness |
0.180 |
| Oil Ring Thickness |
0.111 |
| Piston Head Type |
Dish |
| Cylinder Head |
ECOBOOST V6 |
| Bore Diameter |
93.00 |
| Piston Volume |
-9.70 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
3.5L EcoBoost Gen 2 V6 |
| Add-On |
905-073-MW |
| Prop 65 Yes/No |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
905-2250-18-51C |
| Second Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Prop 65 (C, R or CR) |
CR |
| Out of Stock Message |
Call for Availability |
| Product Type |
Engine Piston Kit |
| Compression Height |
1.240 |
| Add-On |
JG1001-3661 |
| Industry |
Automotive |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
8.0000 |
