As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LT1 Gen V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 4.065 Bore, 1.326 CD, 0.943 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Chevrolet, LT1 Gen V, 4.065 in. Bore, 1.326 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet LT1, 4.065 Bore, Dish, Set of 8 |
| Bore Diameter |
4.065 |
| Top Compression Ring Thickness |
0.0480 |
| Industry |
Automotive |
| Product Market |
Domestic |
| Title |
JE Pistons - Chevrolet, LT1 Gen V, 4.065 in. Bore, Piston Kit |
| Piston Average Weight |
559 |
| Cylinder Head |
GEN 5 LT1 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.200 |
| Piston Material |
2618 |
| Compression Height |
1.326 |
| Piston Quantity |
8 |
| Product Type |
Engine Piston Kit |
| Piston Pin Wall Thickness |
0.200 |
| Piston Volume |
-13.90 |
| Wrist Pin Length |
2.250 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
0.943 |
| Add-On |
945-073-MW |
| Add-On |
943-2250-20-51C |
| Add-On |
JG31F1-4070-0 |
| Wrist Pin Outer Diameter |
0.943 |
| Engine - Web |
LT1 Gen V |
| Second Compression Ring Thickness |
0.0600 |
| Piston Head Type |
Dish |
| Title - Web |
JE Pistons Chevrolet LT1 Gen V Piston Kit - 4.065 in. Bore - 1.326 in. CH, -13.90 CC |
| Piston Series |
JE Pistons |
| Engine |
LT1 Gen V |
| Prop 65 Yes/No |
Yes |
| Make |
CHEVROLET |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.1175 |
| Piston Pin Length |
2.250 |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
