As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda L15B7 Turbo |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Honda, L15B7 Turbo, 2.894 in. Bore, 9.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 2.894 Bore, 1.126 CD, 0.787 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda L15B7, 73.50 Bore, Dish, Set of 4 |
| Bore Diameter |
73.50 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Top Compression Ring Thickness |
0.0400 |
| Piston Average Weight |
209 |
| Industry |
Automotive |
| Product Market |
Sport Compact |
| Cylinder Head |
L15A |
| Piston Quantity |
4 |
| Engine - Web |
L15B7 Turbo |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Honda, L15B7 Turbo, 73.50 mm Bore, Piston Kit |
| Ring Set Included |
Yes |
| Make - Web |
Honda |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Add-On |
787-2250-18-51C |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
787-050-MW |
| Make |
HONDA |
| Out of Stock Message |
Call for Availability |
| Title - Web |
JE Pistons Honda L15B7 Turbo Piston Kit - 73.50 mm Bore - 1.126 in. CH, -14.00 CC |
| Piston Head Type |
Dish |
| Piston Volume |
-14.00 |
| Piston Pin Outside Diameter |
0.787 |
| Add-On |
JG1001-2894 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Outer Diameter |
0.787 |
| Compression Height |
1.126 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Forging Type |
Round |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Length |
2.250 |
| Engine |
L15B7 TURBO |
| Ringset Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
