As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda L15B7 Turbo |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 2.874 Bore, 1.126 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Honda, L15B7 Turbo, 2.874 in. Bore, 9.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda L15B7, 73.00 Bore, Dish, Set of 4 |
| Piston Average Weight |
207 |
| Compression Height |
1.126 |
| Bore Diameter |
73.00 |
| Piston Pin Outside Diameter |
0.787 |
| Product Market |
Sport Compact |
| Make |
HONDA |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
L15B7 Turbo |
| Title |
JE Pistons - Honda, L15B7 Turbo, 73.00 mm Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
4 |
| Cylinder Head |
L15A |
| Piston Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.787 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Prop 65 Yes/No |
Yes |
| Add-On |
787-2250-18-51C |
| Piston Volume |
-13.40 |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Add-On |
JG1001-2874 |
| Add-On |
787-050-MW |
| Title - Web |
JE Pistons Honda L15B7 Turbo Piston Kit - 73.00 mm Bore - 1.126 in. CH, -13.40 CC |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Honda |
| Wrist Pin Length |
2.250 |
| Piston Head Type |
Dish |
| Engine |
L15B7 TURBO |
| Engine Type |
ICE |
| Forging Type |
Round |
| Ringset Included |
Yes |
| Piston Pin Length |
2.250 |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
