As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda K20C |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.386 Bore, 1.260 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, Honda, K20C Series, 3.386 in. Bore, 10.50:1, Dome, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Honda K20A, 86.00 Bore, Dome, Set of 4 |
| Piston Head Type |
Dome |
| Top Compression Ring Thickness |
0.0480 |
| Make |
HONDA |
| Title |
JE Pistons - Honda, K Series, 86.00 mm Bore, Piston Kit |
| Compression Height |
1.260 |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Piston Series |
JE Pistons |
| Engine - Web |
K Series |
| Wrist Pin Outer Diameter |
0.866 |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
86.00 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Quantity |
4 |
| Piston Pin Outside Diameter |
0.866 |
| Oil Ring Thickness |
0.079 |
| Engine Type |
ICE |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.180 |
| Out of Stock Message |
Call for Availability |
| Ringset Included |
Yes |
| Piston Pin Length |
2.250 |
| Cylinder Head |
K20C |
| Piston Volume |
2.65 |
| Add-On |
866-063-MW |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Honda K Series Piston Kit - 86.00 mm Bore - 1.260 in. CH, 2.65 CC |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Engine |
K20C SERIES |
| Add-On |
866-2250-18-51C |
| Add-On |
JG1201-3386 |
| Piston Material |
2618 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine Detail |
K20C Series |
| Ring Set Included |
Yes |
| Make - Web |
Honda |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0480 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
