As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ EURO 2015+ USA |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.287 Bore, 1.165 CD, 0.905 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T TSI - 2013+ Euro / 2015+ USA - 23mm Pin, 3.287 in. Bore, 9.60:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.50 Bore, Dish, Set of 4 |
| Engine Detail |
2.0T TSI 2013+ Euro 2015+ USA 23 mm Pin |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Engine |
2.0T TSI 2013+ Euro 2015+ USA 23 mm Pin |
| Prop 65 Yes/No |
Yes |
| Piston Series |
JE Pistons |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 83.50 mm Bore - 1.165 in. CH, -8.40 CC |
| Piston Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Make - Web |
Volkswagen |
| Engine Type |
ICE |
| Add-On |
905-073-MW |
| Add-On |
JG1001-3287 |
| Add-On |
905-2250-18-51C |
| Piston Head Type |
Dish |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
4 |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Piston Pin Outside Diameter |
0.905 |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 83.50 mm Bore, Piston Kit |
| Forging Type |
Round |
| Product Market |
European |
| Piston Volume |
-8.40 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.111 |
| Compression Height |
1.165 |
| Bore Diameter |
83.50 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Wall Thickness |
0.180 |
| Cylinder Head |
2.0 TSI |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Make |
VOLKSWAGEN |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
2.0T TSI |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
