As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ EURO 2015+ USA |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.165 CD, 0.905 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, VW, 2.0T TSI - 2013+ Euro / 2015+ USA - 23mm Pin, 3.248 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 82.50 Bore, Dish, Set of 4 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Make - Web |
Volkswagen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
JG1001-3250 |
| Ringset Included |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
2.0 TSI |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Piston Head Type |
Dish |
| Industry |
Automotive |
| Add-On |
905-2250-18-51C |
| Piston Pin Length |
2.250 |
| Add-On |
905-073-MW |
| Out of Stock Message |
Call for Availability |
| Engine |
2.0T TSI 2013+ Euro 2015+ USA 23 mm Pin |
| Engine Detail |
2.0T TSI 2013+ Euro 2015+ USA 23 mm Pin |
| Forging Type |
Round |
| Oil Ring Thickness |
0.111 |
| Product Type |
Engine Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Piston Quantity |
4 |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 82.50 mm Bore - 1.165 in. CH, -4.50 CC |
| Bore Diameter |
82.50 |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 82.50 mm Bore, Piston Kit |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Make |
VOLKSWAGEN |
| Piston Pin Wall Thickness |
0.180 |
| Piston Material |
2618 |
| Piston Pin Outside Diameter |
0.905 |
| Compression Height |
1.165 |
| Engine Type |
ICE |
| Product Market |
European |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Length |
2.250 |
| Piston Volume |
-4.50 |
| Ring Set Included |
Yes |
| Engine - Web |
2.0T TSI |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
