As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.165 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T TSI - 13-15 - 22mm Pin, 3.268 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.00 Bore, Dish, Set of 4 |
| Forging Type |
FSR |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Quantity |
4 |
| Piston Head Type |
Dish |
| Make |
VOLKSWAGEN |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Compression Height |
1.165 |
| Piston Pin Wall Thickness |
0.150 |
| Engine - Web |
2.0T TSI |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 83.00 mm Bore, Piston Kit |
| Ringset Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.866 |
| Bore Diameter |
83.00 |
| Piston Pin Material |
5115 |
| Product Market |
European |
| Oil Ring Thickness |
0.111 |
| Top Compression Ring Thickness |
0.0400 |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-5.20 |
| Piston Material |
2618 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Add-On |
JG1001-3268 |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 83.00 mm Bore - 1.165 in. CH, -5.20 CC |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Engine |
2.0T TSI 2013-2015 22 mm Pin |
| Add-On |
866-063-MW |
| Cylinder Head |
2.0 TSI |
| Add-On |
866-2250-15-51C |
| Piston Pin Length |
2.250 |
| Wrist Pin Length |
2.250 |
| Make - Web |
Volkswagen |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine Detail |
2.0T TSI 2013-2015 22 mm Pin |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
