As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 04-08 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.165 CD, 0.827 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T TSI - 04-08 - 21mm Pin, 3.268 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.00 Bore, Dish, Set of 4 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Ring Set Included |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Outside Diameter |
0.827 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-5.20 |
| Compression Height |
1.165 |
| Piston Quantity |
4 |
| Engine - Web |
2.0T TSI |
| Wrist Pin Length |
2.250 |
| Cylinder Head |
2.0 TSI |
| Add-On |
827-2250-15-51C |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 83.00 mm Bore - 1.165 in. CH, -5.20 CC |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 83.00 mm Bore, Piston Kit |
| Bore Diameter |
83.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Product Market |
European |
| Add-On |
JG1001-3268 |
| Add-On |
827-063-MW |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Engine |
2.0T TSI 04-08 21 mm Pin |
| Piston Head Type |
Dish |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Make |
VOLKSWAGEN |
| Wrist Pin Outer Diameter |
0.827 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine Detail |
2.0T TSI 04-08 21 mm Pin |
| Piston Series |
JE Pistons |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Volkswagen |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
