As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 04-08 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.165 CD, 0.827 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 2.0T TSI - 04-08 - 21mm Pin, 3.248 in. Bore, 9.60:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Volkswagen 2.0L Turbo, 82.50 Bore, Dish, Set of 4 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Wrist Pin Outer Diameter |
0.827 |
| Bore Diameter |
82.50 |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Make |
VOLKSWAGEN |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 82.50 mm Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.165 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine Type |
ICE |
| Piston Volume |
-7.10 |
| Add-On |
827-2250-15-51C |
| Industry |
Automotive |
| Cylinder Head |
2.0 TSI |
| Add-On |
827-063-MW |
| Piston Quantity |
4 |
| Forging Type |
FSR |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.827 |
| Add-On |
JG1001-3250 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.250 |
| Engine - Web |
2.0T TSI |
| Ring Set Included |
Yes |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Engine |
2.0T TSI 04-08 21 mm Pin |
| Piston Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Ringset Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 82.50 mm Bore - 1.165 in. CH, -7.10 CC |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine Detail |
2.0T TSI 04-08 21 mm Pin |
| Make - Web |
Volkswagen |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
