As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T FSI 04-08 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.287 Bore, 1.165 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T FSI - 04-08 - 20mm Pin, 3.287 in. Bore, 10.00:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.50 Bore, Dish, Set of 4 |
| Compression Height |
1.165 |
| Engine Type |
ICE |
| Product Market |
European |
| Wrist Pin Outer Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Forging Type |
FSR |
| Make |
VOLKSWAGEN |
| Piston Pin Material |
5115 |
| Piston Pin Wall Thickness |
0.180 |
| Oil Ring Thickness |
0.111 |
| Engine - Web |
2.0T FSI |
| Piston Quantity |
4 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Product Type |
Engine Piston Kit |
| Title |
JE Pistons - Volkswagen, 2.0T FSI, 83.50 mm Bore, Piston Kit |
| Piston Pin Outside Diameter |
0.787 |
| Bore Diameter |
83.50 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Volume |
-6.80 |
| Wrist Pin Length |
2.250 |
| Piston Series |
JE Pistons |
| Industry |
Automotive |
| Cylinder Head |
2.0 TFSI |
| Title - Web |
JE Pistons Volkswagen 2.0T FSI Piston Kit - 83.50 mm Bore - 1.165 in. CH, -6.80 CC |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 Yes/No |
Yes |
| Piston Material |
2618 |
| Piston Pin Length |
2.250 |
| Add-On |
JG1001-3287 |
| Add-On |
787-2250-18-51C |
| Add-On |
787-050-MW |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Volkswagen |
| Engine Detail |
2.0T FSI 04-08 20 mm Pin |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Engine |
2.0T FSI 04-08 20 mm Pin |
| Ringset Included |
Yes |
| Piston Head Type |
Dish |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
