As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Porsche 3.0L 911 |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Porsche, Aircooled - 6 Cyl, 4.016 in. Bore, 10.50:1, Dome, Single Piston |
| Description_DES |
Piston Single, 2618, Dome, 4.016 Bore, 1.335 CD, 0.866 Pin, Set of 1. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Porsche 3.0L, 102.00 Bore, Dome, Set of 1 |
| Description_SHO |
Piston |
| Top Compression Ring Thickness |
0.0480 |
| Wrist Pin Wall Thickness |
0.150 |
| Compression Height |
1.335 |
| Bore Diameter |
102.00 |
| Product Market |
European |
| Cylinder Head |
3.0 Liter |
| Piston Material |
2618 |
| Forging Type |
Round |
| Title |
JE Pistons - Porsche, 3.0L Aircooled, 102.00 mm Bore, Piston |
| Piston Volume |
37.70 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.119 |
| Piston Pin Material |
9310 |
| Engine - Web |
3.0L Aircooled |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Piston Quantity |
1 |
| Make |
PORSCHE |
| Piston Pin Outside Diameter |
0.866 |
| Product Type |
Engine Piston |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>European |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.500 |
| Ring Set Included |
Yes |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Add-On |
866-063-MW |
| Ringset Included |
Yes |
| Add-On |
JG3101-4020-2 |
| Engine Type |
ICE |
| Piston Head Type |
Dome |
| Title - Web |
JE Pistons Porsche 3.0L Aircooled Piston - 102.00 mm Bore - 1.335 in. CH, 37.70 CC |
| Add-On |
866-2500-15-93C |
| Piston Pin Length |
2.500 |
| Engine |
3.0L Aircooled |
| Piston Series |
JE Pistons |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Make - Web |
Porsche |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
