As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Porsche 3.0L 911 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.858 Bore, 1.335 CD, 0.866 Pin, Set of 1. |
| Description_EXT |
JE, Porsche, Aircooled - 6 Cyl, 3.858 in. Bore, 10.50:1, Dome, Single Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston |
| Description_TLE |
Porsche 3.0L, 98.00 Bore, Dome, Set of 1 |
| Industry |
Automotive |
| Add-On |
866-2500-15-93C |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3858 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
3.0L Aircooled |
| Piston Volume |
41.70 |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>European |
| Piston Pin Length |
2.500 |
| Product Type |
Engine Piston |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.500 |
| Second Compression Ring Thickness |
0.0480 |
| Forging Type |
Round |
| Cylinder Head |
3.0 Liter |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Title - Web |
JE Pistons Porsche 3.0L Aircooled Piston - 98.00 mm Bore - 1.335 in. CH, 41.70 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Make - Web |
Porsche |
| Engine Type |
ICE |
| Piston Pin Material |
9310 |
| Top Compression Ring Thickness |
0.0400 |
| Make |
PORSCHE |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.335 |
| Title |
JE Pistons - Porsche, 3.0L Aircooled, 98.00 mm Bore, Piston |
| Bore Diameter |
98.00 |
| Piston Pin Outside Diameter |
0.866 |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Piston Quantity |
1 |
| Product Market |
European |
| Piston Head Type |
Dome |
| Piston Series |
JE Pistons |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
3.0L Aircooled |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
