As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Porsche 2.0L |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.150 Bore, 1.335 CD, 0.866 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Porsche, LTG, 3.150 in. Bore, 9.50:1, Dome, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Porsche 2.0L, 80.00 Bore, Dome, Set of 6 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Piston Head Type |
Dome |
| Piston Pin Material |
9310 |
| Piston Series |
JE Pistons |
| Compression Height |
1.335 |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
European |
| Make |
PORSCHE |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Bore Diameter |
80.00 |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Title |
JE Pistons - Porsche, 2.0L Aircooled, 80.00 mm Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.866 |
| Product Type |
Engine Piston Kit |
| Piston Volume |
34.10 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Quantity |
6 |
| Engine Type |
ICE |
| Forging Type |
Round |
| Engine - Web |
2.0L Aircooled |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.500 |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3150 |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
866-063-MW |
| Cylinder Head |
2.0 Liter |
| Piston Pin Length |
2.500 |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Piston Material |
2618 |
| Title - Web |
JE Pistons Porsche 2.0L Aircooled Piston Kit - 80.00 mm Bore - 1.335 in. CH, 34.10 CC |
| Ringset Included |
Yes |
| Engine |
2.0L |
| Add-On |
866-2500-15-93C |
| Prop 65 Yes/No |
Yes |
| Make - Web |
Porsche |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
7.0000 |
