As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Cadillac 2.0L |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.386 Bore, 1.261 CD, 0.945 Pin, Set of 4. |
| Description_EXT |
JE, Cadillac, LTG, 3.386 in. Bore, 9.50:1, Dome, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Cadillac 2.0L, 86.00 Bore, Dome, Set of 4 |
| Forging Type |
FSR |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.111 |
| Piston Pin Outside Diameter |
0.945 |
| Piston Quantity |
4 |
| Piston Pin Material |
5115 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Make |
CADILLAC |
| Bore Diameter |
86.00 |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Title |
JE Pistons - Cadillac, LTG, 86.00 mm Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.945 |
| Wrist Pin Length |
2.250 |
| Engine - Web |
LTG |
| Ring Set Included |
Yes |
| Compression Height |
1.261 |
| Top Compression Ring Thickness |
0.0400 |
| Product Market |
Sport Compact |
| Piston Volume |
-1.30 |
| Title - Web |
JE Pistons Cadillac LTG Piston Kit - 86.00 mm Bore - 1.261 in. CH, -1.30 CC |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dome |
| Engine |
LTG |
| Piston Pin Length |
2.250 |
| Add-On |
JG1001-3386 |
| Cylinder Head |
LTG |
| Industry |
Automotive |
| Piston Pin Wall Thickness |
0.150 |
| Add-On |
945-073-MW |
| Piston Material |
2618 |
| Add-On |
945-2250-15-51C |
| Prop 65 Yes/No |
Yes |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Cadillac |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
9.0000 |
| Weight |
5.0000 |
