As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.165 CD, 0.866 Pin, Set of 4. |
| Description_EXT |
JE, VW, 2.0T TSI - 13-15 - 22mm Pin, 3.268 in. Bore, 9.60:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.00 Bore, Dish, Set of 4 |
| Engine |
2.0T TSI 2013-2015 22 mm Pin |
| Ringset Included |
Yes |
| Piston Pin Material |
5115 |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Engine - Web |
2.0T TSI |
| Product Market |
European |
| Compression Height |
1.165 |
| Piston Quantity |
4 |
| Piston Head Type |
Dish |
| Piston Volume |
-7.80 |
| Forging Type |
Round |
| Oil Ring Thickness |
0.111 |
| Product Type |
Engine Piston Kit |
| Top Compression Ring Thickness |
0.0400 |
| Piston Material |
2618 |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 83.00 mm Bore, Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Make |
VOLKSWAGEN |
| Piston Pin Outside Diameter |
0.866 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
83.00 |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
JG1001-3268 |
| Piston Pin Length |
2.250 |
| Add-On |
866-063-MW |
| Cylinder Head |
2.0 TSI |
| Add-On |
866-2250-15-51C |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 83.00 mm Bore - 1.165 in. CH, -7.80 CC |
| Wrist Pin Length |
2.250 |
| Make - Web |
Volkswagen |
| Engine Detail |
2.0T TSI 2013-2015 22 mm Pin |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
