Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.360 Bore, 1.865 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.360 in. Bore, 1.865 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Chrysler 440, 4.360 Bore, Dish, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Second Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Piston Pin Length |
2.930 |
| Make - Web |
Chrysler |
| Engine Type |
ICE |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine |
Big Block |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.360 in. Bore - 1.865 in. CH, -24.00 CC |
| Ringset Included |
No |
| Add-On |
990-042-CS |
| Piston Series |
SRP |
| Add-On |
990-2930-18-51S |
| Prop 65 Yes/No |
Yes |
| Add-On |
S100S8-4360-5 |
| Product Market |
Domestic |
| Piston Head Type |
Dish |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.360 |
| Piston Pin Outside Diameter |
0.990 |
| Cylinder Head |
440 WEDGE |
| Make |
CHRYSLER |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Piston Material |
4032 |
| Oil Ring Thickness |
0.188 |
| Piston Pin Wall Thickness |
0.180 |
| Title |
SRP - Chrysler, Big Block, 4.360 in. Bore, Piston Kit |
| Piston Volume |
-24.00 |
| Piston Average Weight |
700 |
| Compression Height |
1.865 |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Wrist Pin Length |
2.930 |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
