JE Pistons 345794S Piston Single, 4032, Flat Top, 4.000 Bore, 1.790 CD, 0.984 Pin, Set of 1.

2 sold in last 8 days
JE Pistons
ds_BHXG_345794S
Engine Piston
$216.42
customers are viewing this product
JE Pistons 345871R Piston Single, 2618, Dome, 3.701 Bore, 1.161 CD, 0.827 Pin, Set of 1.
JE Pistons 345871R Piston Single, 2618, Dome, 3.701 Bore, 1.161 CD, 0.827 Pin, Set of 1.
$289.06
Manley Performance 597400PC-1 Manley Piston Single, PIST-3.917/99.5mm/1.220 CD/DOME
Manley Performance 597400PC-1 Manley Piston Single, PIST-3.917/99.5mm/1.220 CD/DOME
$190.49
JE Pistons 345794S Piston Single, 4032, Flat Top, 4.000 Bore, 1.790 CD, 0.984 Pin, Set of 1.
Details

Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.

Specifications:

Description_ASM Chrysler Small Block 318
Description_DEF Engine Piston
Description_DES Piston Single, 4032, Flat Top, 4.000 Bore, 1.790 CD, 0.984 Pin, Set of 1.
Description_FAB
  • Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
  • Dedicated forging helps optimize strength and weight throughout the piston design
  • Perfect for street/strip applications
  • Forced pin oiling for improved pin lubrication
  • Made 100% in the USA
Description_EXT SRP, Chrysler, Small Block Chrysler, 4.000 in. Bore, 1.790 CD, Flat Top, Single Piston
Description_INV SRP, Piston
Description_TLE Chrysler 318, 4.000 Bore, Flat, Set of 1
Description_MKT Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Description_SHO Piston
Cylinder Head 340 WEDGE
Industry Automotive
Prop 65 (C, R or CR) CR
Top Compression Ring Thickness 0.0640
Bore Diameter 4.000
Category Hierarchy Auto>SRP Pistons>SRP>Single Replacement Pistons
Product Type Engine Piston
Add-On 984-2750-15-51S
Add-On 990-042-CS
Add-On S100S8-4000-5
Out of Stock Message Call for Availability
Make - Web Chrysler
Prop 65 Yes/No Yes
Second Compression Ring Thickness 0.0640
Title - Web SRP Chrysler Small Block Piston - 4.000 in. Bore - 1.790 in. CH, -5.00 CC
Wrist Pin Length 2.750
Wrist Pin Material 5115 Low Carbon Steel, Case Hardened
Prop 65 - Short Label Prop 65 Warning Label.JPG
Engine Small Block
Title SRP - Chrysler, Small Block, 4.000 in. Bore, Piston
Piston Pin Length 2.750
Piston Pin Outside Diameter 0.984
Piston Material 4032
Product Market Domestic
Make CHRYSLER
Piston Volume -5.00
Oil Ring Thickness 0.188
Piston Head Type Flat
Forging Type FSR
Piston Pin Material 5115
Piston Series SRP
Ringset Included No
Engine Type ICE
Compression Height 1.790
Piston Pin Wall Thickness 0.150
Wrist Pin Outer Diameter 0.984
Wrist Pin Wall Thickness 0.150
Engine - Web Small Block
Ring Set Included No
Length 5.0000
Width 5.0000
Height 5.0000
Weight 1.0000
