Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 318 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.000 Bore, 1.790 CD, 0.984 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.000 in. Bore, 1.790 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Chrysler 318, 4.000 Bore, Flat, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Piston Series |
SRP |
| Wrist Pin Length |
2.750 |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.984 |
| Bore Diameter |
4.000 |
| Oil Ring Thickness |
0.188 |
| Top Compression Ring Thickness |
0.0640 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.790 |
| Product Market |
Domestic |
| Piston Head Type |
Flat |
| Piston Pin Outside Diameter |
0.984 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.000 in. Bore - 1.790 in. CH, -5.00 CC |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
340 WEDGE |
| Make |
CHRYSLER |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Title |
SRP - Chrysler, Small Block, 4.000 in. Bore, Piston Kit |
| Piston Material |
4032 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
990-042-CS |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.750 |
| Engine |
Small Block |
| Add-On |
S100S8-4000-5 |
| Piston Volume |
-5.00 |
| Industry |
Automotive |
| Add-On |
984-2750-15-51S |
| Make - Web |
Chrysler |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
