Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C Cleveland |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.040 Bore, 1.300 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.300 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 351 Cleveland, 4.040 Bore, Dish, Set of 8 |
| Ring Set Included |
No |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Add-On |
S100S8-4040-5 |
| Cylinder Head |
CLEVELAND |
| Piston Volume |
-16.00 |
| Industry |
Automotive |
| Add-On |
927-042-CS |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
912-2750-14-51S |
| Product Type |
Engine Piston Kit |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine |
Small Block |
| Piston Material |
4032 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.300 in. CH, -16.00 CC |
| Second Compression Ring Thickness |
0.0640 |
| Make - Web |
Ford |
| Piston Average Weight |
478 |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.750 |
| Piston Pin Wall Thickness |
0.140 |
| Piston Head Type |
Dish |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Compression Height |
1.300 |
| Oil Ring Thickness |
0.218 |
| Bore Diameter |
4.040 |
| Piston Series |
SRP |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0640 |
| Make |
FORD |
| Engine Type |
ICE |
| Product Market |
Domestic |
| Piston Pin Outside Diameter |
0.912 |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.912 |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Wrist Pin Length |
2.750 |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
